4-Seater Electric Golf Cart – 48V 5KW AC with 80-100km Range | YIPU-GC-B 2S+2S
4-Seater Electric Golf Cart – 48V 5KW AC with 80-100km Range | YIPU-GC-B 2S+2S
Regular price
$8,669.00 USD
Regular price
$8,853.00 USD
Sale price
$8,669.00 USD
Quantity
Couldn't load pickup availability
YIPU-GC-B 2S+2S – 4-Seater Electric Golf Cart | 48V 5KW AC Motor with Long Range
The YIPU-GC-B 2S+2S is a reliable and efficient 4-seater electric golf cart designed for golf courses, resorts, hotels, and community transport. Powered by a 48V 5KW AC motor with 80-100km range, this model combines durability, comfort, and performance for daily commercial use.
🚗 Model Overview
| Feature | Specification |
|---|---|
| Model | YIPU-GC-B 2S+2S |
| Seating Capacity | 4 passengers |
| Dimensions (L×W×H) | 2910 × 1330 × 1830 mm (1930 mm with roof) |
| System Voltage | 48V |
| Motor | 5KW AC Motor |
| Controller | Haike dedicated controller, 48V |
| Battery | 150AH, 6 units |
| Range | 80-100 km |
| Ideal For | Golf courses, resorts, hotels, communities, campuses |
🔋 Electrical System
| Component | Specification |
|---|---|
| Motor | 5KW AC motor |
| Controller | Haike dedicated controller, 48V |
| Battery | 150AH (6 units) |
| Charger | Intelligent high-frequency on-board charger |
| Charging Time | 8 hours |
⚙️ Performance Specifications
| Specification | Details |
|---|---|
| Maximum Speed | ≤30 km/h |
| Range | 80-100 km |
| Maximum Gradeability | 15% |
| Braking Distance | ≤4 m |
| Minimum Turning Radius | 3.5 m |
| Ground Clearance | 120 mm |
| Dimensions (L×W×H) | 2910 × 1330 × 1830 mm (1930 mm with roof) |
| Wheelbase | 1670 mm |
| Front/Rear Track Width | 880 mm / 990 mm |
| Curb Weight | 580 kg |
🖥️ Dashboard & Controls
| Feature | Specification |
|---|---|
| Instrument Panel | Multi-functional LCD display showing speed, mileage, battery level, and system status |
| Steering System | Rack and pinion steering gear |
| Switches | Start switch, light combination switch, forward/reverse gear switch |
🏗️ Body & Chassis Construction
| Component | Specification |
|---|---|
| Body Material | Steel frame + ABS engineering plastic molded parts |
| Frame | Steel frame construction |
| Seats | Automotive cold foam + high-resilience PU leather fabric |
| Front Windshield | Acrylic folding windshield |
| Rearview Mirrors | Left and right folding mirrors with integrated turn signal lamps |
| Lighting | Front and rear combined LED lights: headlamps, turn signals, daytime running lights; rear brake lights, turn signals, position lights |
| Audio & Alerts | Electric horn, reverse buzzer |
| Safety Features | Two-point telescopic seat belts, front bumper |
🔧 Suspension & Braking System
| Component | Specification |
|---|---|
| Front Suspension | Independent suspension |
| Rear Suspension | Integral rear axle, leaf spring + hydraulic damper |
| Braking System | Four-wheel disc brakes + electromagnetic parking brake |
| Wheels & Tires | 12-inch aluminum wheels |
🎨 Customization Options
| Option | Available Choices |
|---|---|
| Multimedia Screen | Optional large screen with: time display, speed, mileage, battery level, reverse image, Bluetooth, radio |
| Colors | Custom colors available upon request |
| Front Bumper | Included as standard |
🌟 Key Features & Benefits
| Feature | Benefit |
|---|---|
| Long Range | 80-100 km per charge – all-day operation |
| 5KW AC Motor | Reliable power for daily use |
| Haike Controller | Proven reliability |
| Four-Wheel Disc Brakes | Superior stopping power, enhanced safety |
| Electromagnetic Parking Brake | Automatic hill-hold safety |
| LED Lighting Package | Energy-efficient, bright, long-lasting |
| Turn Signal Mirrors | Enhanced visibility and safety |
| Comfortable Seats | Automotive-grade foam + PU leather |
| Customizable Colors | Match your fleet or brand identity |
🌍 Ideal Applications
| Industry | How YIPU-GC-B 2S+2S Is Used |
|---|---|
| Golf Courses | Player and guest transport between holes |
| Resorts & Hotels | Guest shuttles across property |
| Communities | Resident transport within gated communities |
| Campuses | Staff and visitor mobility |
| Corporate Campuses | Internal personnel transport |
| Rental Fleets | Daily rental operations |
✅ Why Choose YIPU-GC-B 2S+2S
| Advantage | Benefit |
|---|---|
| Long Range | 80-100km – fewer charging stops |
| Reliable Powertrain | 5KW AC motor + Haike controller |
| Four-Wheel Disc Brakes | Maximum safety |
| LED Lights Throughout | Modern look, energy efficient |
| Comfortable Interior | Automotive-grade seats and finishes |
| Customizable | Colors and multimedia options |
| Compact Size | Easy maneuverability in tight spaces |
| Export Ready | Full documentation for international shipping |
📦 Warranty & Support
| Coverage | Details |
|---|---|
| Vehicle Warranty | One-year comprehensive warranty |
| Technical Support | Lifelong technical support |
| Spare Parts | Available upon request |
📏 Technical Specifications Summary
| Specification | Details |
|---|---|
| Dimensions (L×W×H) | 2910 × 1330 × 1830 mm (1930 mm with roof) |
| Wheelbase | 1670 mm |
| Front/Rear Track Width | 880 mm / 990 mm |
| Ground Clearance | 120 mm |
| Curb Weight | 580 kg |
| Passenger Capacity | 4 persons |
| System Voltage | 48V |
| Motor | 5KW AC |
| Controller | Haike dedicated controller, 48V |
| Battery | 150AH (6 units) |
| Max Speed | ≤30 km/h |
| Max Gradient | 15% |
| Range | 80-100 km |
| Braking Distance | ≤4 m |
| Minimum Turning Radius | 3.5 m |
| Charging Time | 8 hours |
| Wheels | 12-inch aluminum wheels |
| Brake System | Four-wheel disc + electromagnetic parking brake |
📦 Shipping & Delivery
| Destination | Estimated Transit Time |
|---|---|
| USA (West Coast) | 18-22 days by sea |
| USA (East Coast) | 25-30 days by sea |
| Israel | 20-25 days by sea |
| Europe | 25-30 days by sea |
| UAE/Middle East | 18-22 days by sea |
| Southeast Asia | 15-20 days by sea |
Shipping Terms: FOB, CIF, DDP available upon request.
👉 Inquire About YIPU-GC-B 2S+2S Pricing & Availability
