YIPU-T 6T – 1-Seater Electric Tow Tractor | 72V Industrial Tug with 3000kg Towing Capacity
The YIPU-T 6T is a powerful electric tow tractor engineered for heavy-duty towing in industrial environments. Featuring a 72V high-capacity battery system and an 11.5KW AC motor, this compact but mighty tug delivers 2000-3000kg towing capacity for airports, warehouses, factories, seaports, and logistics centers.
🚜 Model Overview
| Feature | Specification |
|---|---|
| Model | YIPU-T 6T |
| Seating Capacity | 1 driver |
| System Voltage | 72V |
| Motor | 11.5KW AC Motor (Special for Tractors) |
| Controller | Enpower Fully Intelligent Controller |
| Battery | 2V 250Ah × 36 units (72V) High-Capacity Deep-Cycle Flooded Lead-Acid Batteries |
| Body Dimensions | 2300 × 1200 × 2000 mm |
| Wheelbase | 1800 mm |
| Front/Rear Track Width | 960 mm / 960 mm |
| Minimum Ground Clearance | 130 mm |
| Curb Weight | 1050 kg |
| Towing Capacity | 2000-3000 kg |
| Ideal For | Airports, warehouses, factories, seaports, logistics hubs, railway stations |
🔋 Electrical System
| Component | Specification |
|---|---|
| Controller | Enpower Fully Intelligent Controller |
| Battery | 2V 250Ah × 36 units (72V) High-Capacity Deep-Cycle Flooded Lead-Acid Batteries (Special for Tractors) |
| Motor | 11.5KW AC Motor (Special for Tractors) |
| Charger | Intelligent Onboard Charger with Automatic Power-Off When Fully Charged |
| Charging Time | 8-10 hours (at 80% depth of discharge) |
| Charging Input Voltage | 220V |
| Driving Range | 80-100 km |
⚙️ Performance Specifications
| Specification | Details |
|---|---|
| Towing Capacity | 2000-3000 kg |
| Maximum Speed | 28 km/h |
| Maximum Gradeability | 10% |
| Braking Distance | ≤5 m |
| Minimum Turning Radius | 3.5 m |
🪑 Body System
| Component | Specification |
|---|---|
| Seat | Single seat, leather + high-resilience PU |
| Body Construction | Steel frame + sheet metal body |
| Instrument Panel | LCD display showing voltage, current, speed, mileage, lighting, forward/reverse direction signals |
| Rearview Mirrors | Adjustable manual wide-view exterior rearview mirrors |
| Lighting & Signals | LED headlights, turn signals, combined taillights, brake lights, electric horn, reverse buzzer |
| Switches | Ignition switch, forward/reverse gear switch |
| Frame | Steel frame |
| Doors | Sheet metal doors (2 doors) |
| Steering Wheel | Polyurethane foam steering wheel |
🔧 Chassis & Suspension System
| Component | Specification |
|---|---|
| Powertrain System | Continuously Variable Transmission (CVT) system |
| Steering System | Rack and pinion steering + electronic power steering (EPS) |
| Front Axle & Suspension | Integrated front axle |
| Rear Axle & Suspension | Integrated rear axle (18.12:1 ratio) + high-strength leaf springs + hydraulic shock absorbers |
| Braking System | Drum hydraulic brakes, dual-circuit braking system, parking brake, brake booster |
| Wheels | Front wheels: 500-8 | Rear wheels: 650-10 hubs |
🌟 Key Features & Benefits
| Feature | Benefit |
|---|---|
| 2000-3000kg Towing Capacity | Powerful enough for baggage trains, cargo carts, and industrial trailers |
| 11.5KW AC Motor | High torque for heavy loads, smooth acceleration |
| Enpower Controller | Reliable, intelligent power management |
| Deep-Cycle Batteries | 72V system with 250Ah cells – long-lasting, tractor-specific design |
| CVT Transmission | Smooth, effortless operation |
| EPS Power Steering | Easy maneuverability even at full load |
| Compact Size | 2300mm length – navigates tight spaces |
| Tight Turning Radius | 3.5m – excellent maneuverability |
| Dual-Circuit Brakes | Redundant braking for safety |
| Brake Booster | Enhanced stopping power with heavy loads |
| 80-100km Range | All-day operation on a single charge |
| Quiet Electric Operation | No noise pollution – ideal for indoor use |
| Zero Emissions | Environmentally friendly, safe for enclosed spaces |
🌍 Ideal Applications
| Industry | How YIPU-T 6T Is Used |
|---|---|
| Airports | Towing baggage trains, cargo carts, and service equipment |
| Warehouses & Distribution Centers | Moving multiple loaded pallets, towing trailer trains |
| Factories & Manufacturing Plants | Transporting materials between production areas |
| Seaports & Shipping Terminals | Moving cargo containers and equipment |
| Railway Stations | Towing luggage carts and service vehicles |
| Logistics Hubs | Sorting facility material movement |
| Large Retail Distribution | Warehouse towing operations |
| Agricultural Operations | Towing farm equipment and produce trailers |
🎨 Customization Options
| Option | Available Choices |
|---|---|
| Towing Hitch | Fifth wheel, drawbar, or custom coupling |
| Battery | Standard deep-cycle or lithium upgrade option |
| Lighting Package | Work lights, strobe lights for safety |
| Communications | Two-way radio mounting |
| Seat Comfort | Suspension seat upgrade |
| Branding | Custom logos, decals, fleet numbering |
| Color | Standard or custom colors |
✅ Why Choose YIPU-T 6T
| Advantage | Benefit |
|---|---|
| Industrial-Grade Power | 11.5KW motor specifically designed for tractors |
| Substantial Towing Capacity | 3000kg – handles heavy loads with ease |
| Tractor-Specific Batteries | Deep-cycle cells optimized for towing applications |
| Enpower Controller | Proven reliability |
| CVT Transmission | Operator-friendly, reduces fatigue |
| EPS Power Steering | Effortless control even at capacity |
| Compact & Maneuverable | Works in tight spaces |
| Long Range | 80-100km – supports multi-shift operations |
| Quiet Operation | No noise pollution in sensitive areas |
| Zero Emissions | Safe for indoor warehouse use |
| Dual-Circuit Brakes | Enhanced safety with heavy loads |
| Export Ready | Full documentation for international shipping |
📦 Warranty & Support
| Coverage | Details |
|---|---|
| Vehicle Warranty | One-year comprehensive warranty |
| Battery Warranty | One-year warranty on deep-cycle batteries |
| Technical Support | Lifelong technical support |
| Spare Parts | Available upon request |
📏 Technical Specifications Summary
| Specification | Details |
|---|---|
| Dimensions (L×W×H) | 2300 × 1200 × 2000 mm |
| Wheelbase | 1800 mm |
| Front/Rear Track Width | 960 mm / 960 mm |
| Minimum Ground Clearance | 130 mm |
| Curb Weight | 1050 kg |
| Towing Capacity | 2000-3000 kg |
| Passenger Capacity | 1 driver |
| System Voltage | 72V |
| Motor | 11.5KW AC motor (tractor-spec) |
| Controller | Enpower fully intelligent controller |
| Battery | 2V 250Ah × 36 units (72V) deep-cycle flooded lead-acid |
| Max Speed | 28 km/h |
| Max Gradient | 10% |
| Range | 80-100 km |
| Braking Distance | ≤5 m |
| Minimum Turning Radius | 3.5 m |
| Charging Time | 8-10 hours |
| Charging Input Voltage | 220V |
| Wheels | Front: 500-8 / Rear: 650-10 hubs |
📦 Shipping & Delivery
| Destination | Estimated Transit Time |
|---|---|
| USA (West Coast) | 18-22 days by sea |
| USA (East Coast) | 25-30 days by sea |
| Israel | 20-25 days by sea |
| Europe | 25-30 days by sea |
| UAE/Middle East | 18-22 days by sea |
| Southeast Asia | 15-20 days by sea |
| Australia | 20-25 days by sea |
| South Africa | 25-30 days by sea |
Shipping Terms: FOB, CIF, DDP available upon request.
